PowerSnap Marine Panel Assembly – Two 30A, 125V Receptacles

HyPower PowerSnap Marine Panel Assembly – Two 30A, 125V Receptacles

HyPower PowerSnap Marine Panel Assembly featuring two 30A, 125V receptacles and standard circuit breakers with 10,000 AIR interrupting ratings and overload and overcurrent magnetic-trip protection for compatible PowerPort marine power pedestals.

This PowerSnap Marine Panel Assembly is designed for compatible HyPower PowerPort configurations requiring two 30-amp, 125-volt shore power receptacles. As part of the modular PowerSnap system, this panel provides a specified electrical outlet arrangement for marina and dockside power distribution applications. The standard configuration utilizes circuit breakers with 10,000 AIR interrupting ratings and overload and overcurrent magnetic-trip protection to help protect properly configured electrical circuits. Ground-fault protection breaker options are also available for applications requiring additional protection under applicable electrical codes, including relevant 2017 National Electrical Code (NEC) requirements. Proper panel selection depends on the existing PowerPort configuration, electrical service, receptacle specifications, breaker requirements, and applicable installation standards.

Key Features & Benefits

• Dual 30A receptacle configuration: Features two 30A, 125V marine shore power receptacles for compatible dockside electrical connections.
• Modular PowerSnap design: Part of the HyPower PowerSnap panel system for select PowerPort marine power pedestal configurations.
• Standard circuit protection: Utilizes standard circuit breakers providing overload and overcurrent magnetic-trip protection.
• Interrupting rating: Standard circuit breakers feature a 10,000 AIR interrupting rating for appropriately specified electrical applications.
• Ground-fault protection options: Ground-fault circuit breaker configurations are available for installations requiring additional electrical protection under applicable codes.
• Marine power applications: Designed for select marina and dockside electrical distribution systems requiring dual 30A, 125V connections.
• Configuration-specific replacement: Identified by its individual HyPower part number to distinguish it from other PowerSnap receptacle and breaker combinations.
• PowerPort compatibility: Intended for compatible PowerPort installations with matching electrical ratings, panel positions, and connection requirements.

Product Details

Before Ordering

Before ordering, verify the existing PowerPort model, PowerSnap panel position, receptacle configuration, electrical service specifications, and required circuit breaker protection. Confirm that two 30A, 125V receptacles are appropriate for the intended installation and that the standard 10,000 AIR breakers meet the applicable electrical requirements. Ground-fault protection breakers are available in applicable configurations but should not be assumed included with this standard panel assembly. Review current electrical code requirements, including any applicable NEC provisions, to determine the required protection type and trip characteristics. Electrical installation and replacement should be performed by a licensed or qualified electrician.

Have questions about compatibility, available ground-fault protection options, or product availability? Contact the HyPower team for product guidance.
